CMX88AB

Contractor 8x8 HDMI2.0 4K Matrix

Available Colours
Black matt
  • Contractor 8x8 HDMI2.0 4K Matrix
  • Supports 4K 60Hz 4:4:4
  • Supports HDMI2.0 18Gbps spec, HDR
  • 8x HDMI inputs / 8x HDMI outputs
  • 8x Coaxial, 8x Analog aud. breakout
  • Independent video down conversion
  • Advanced EDID management
  • HDCP 2.2 compliant
  • RRP: $3,999.00

CLEARANCE ITEM

WAS $2,599.00 INC GST

NOW $1,949.00 INC GST

LIMITED STOCK AVAILABLE

Our Contractor CMX88AB 4K HDMI Matrix offers unprecedented performance and value for the custom installation market.

The CMX88AB supports HDMI2.0 with HDCP2.2, allowing distribution of eight HDMI sources to eight displays. This enables all sources to be viewed as required within a matrix configuration. The unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 8-Way matrix also includes audio breakout, EDID management and a web browser interface module for control and configuration of the matrix.

Key Features:

  • Features 8x HDMI inputs which can be independently routed to 8x HDMI outputs
  • Supports HDMI2.0 18Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Independent video down conversion on all HDMI outputs allowing for displays only capable of supporting lower 4K video resolutions (4K 60Hz 4:2:0) to receive native 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently
  • Web interface module for control and configuration of Matrix
  • Control via front panel, IR, RS-232 and TCP/IP
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP2.2 compliant
